TPX 250 - précision compacte

Jusqu'Ă  4 couleurs, un classique polyvalent

TPX 250

High-precision pad printing machine for demanding prints

Your advantage:

  • 1 to 4 colours
  • highest precision and repeat accuracy
  • electropneumatical
  • compact design
  • open inking system
  • wide range of peripherals available


The TPX 250 pad printing machine with an open inking system is driven electropneumatically. The compact printing machine shows its advantages especially at manual workstations.
The colour touch-screen enables a clear, user-friendly operation.
Highest print accuracy and repeatability characterize the TPX 250 as a universally suitable pad printing machine for a variety of applications.

The TPX 250 can be combined with many peripheral devices, e.g. the automatic thinner injection, with rotary or swing table, pad sliding device, etc. Various accessories such as machine bases or coordinate tables are of course also available.

Tampondruckmschine TPX 250
Tampondruckmaschine TPX 250, Farbgeberschlitten

The TPX 250 pad printing machine impresses with its compact design and maximum precision, even for demanding print applications.

Teca-Print Mitarbeiter bei Montage Tampondruckmaschine

Motivated, focussed and enjoying their work: our team during assembly

Tampondruckmaschine TPX 250, ausgerĂŒstet fĂŒr 2-Farbendruck

The pad sliding device makes 2-colour printing easy and reliable.

Technical data TPX 250

Number of colours:
up to 4 colours

Plate sizes:
standard plate widths: 80 / 100 / 120 / 130 / 250 mm
standard plate depths: 80 / 100 / 120 mm

up to 1’400 cycles per hour

Drive system:

Repeat accuracy:
< ± 0.02

Printing force:
700 N (printing force has to be balanced)

Mains connection:
230 V / 50 Hz, 5 – 6 bar air pressure

Air consumption:
0.85 litres / cycle at 6 bar

PLC – HMI touchscreen

100 mm, elektrisch stufenlos verstellbar

Outreach pad carriage:
114 mm

approx. 70 kg without machine base

Dimensions (WxHxD):
471 x 586 x 893 mm

TPX 250 Masszeichnung

Many customers appreciate the medium size of our TPX 250 – compact, precise and reliable.

Request a TPX 250 brochure (pdf):

    Your name (mandatory field)

    Your email address (mandatory field)

    Your company

    Your country (mandatory field)


    Prospektblatt Tampondruckmaschine TPX 250
